What Is a Load in Strength of Materials? Understanding the Basics
Strength of Materials: Zero to Hero – Lesson 1
Whenever we look at a building, bridge, beam or any other structure, we usually notice its shape, size and appearance. But as a civil engineer, there is another question that should immediately come to your mind: what is acting on this structure? A building is not just standing there without any reason. It is continuously carrying its own weight, the weight of people and furniture, and it may also experience wind, earthquake, machinery, vehicles and many other external actions. Understanding these actions is where our journey into Strength of Materials begins.
Before we jump into stress, strain, bending moment or complicated equations, I want you to understand one very basic question: What is a load?
🎥 Watch the Lesson
What Is a Load? | Strength of Materials: Zero to Hero #1
Watch the video below before continuing with the article.
Prefer watching rather than reading? Start with the video above, and then use this article for a deeper understanding and revision.
Let's Understand It With a Simple Example
Take a simple ruler and support it at both ends. Now place a book at the centre of the ruler. You will notice that the ruler bends slightly. If you place a heavier book, the bending becomes more noticeable. If you keep increasing the load, the ruler may eventually undergo permanent deformation or even break.
So, what caused the ruler to bend? The book itself didn't somehow "bend" the ruler. The weight of the book acted on the ruler, and the ruler responded to that external action.
This is the basic idea behind a load.
In structural engineering, we generally use the word load to describe an external action acting on a structure. Depending on the situation, this action can be represented by a force, a moment, pressure or a distributed force. For now, you don't need to worry about all the classifications. Just remember the most important idea: something acts on a structure, and the structure responds to it.
Now think about the structures around you. A floor in a building has to carry people, furniture and other objects. A bridge has to carry vehicles. A roof has to carry its own weight and may also experience wind or other environmental actions. A retaining wall experiences pressure from the soil behind it. A water tank has to resist the pressure of the water stored inside it. All of these are examples of situations where a structure is subjected to loading.
This is why one of the first questions a structural engineer asks while designing a structure is not simply "How strong should I make it?" The first question is often much more basic: "What loads will act on it?"
A Load Is Not Always Just Weight
One of the common mistakes students make when they first hear the word "load" is to immediately think of weight. Weight is certainly an important source of loading, but loads are not limited to weight.
Imagine a tall building during a strong wind. There may be no additional object placed on the building, but the wind is still pushing against its surface. That wind action has to be considered during structural design. Similarly, during an earthquake, the ground moves and the building responds to that movement. The resulting effects also have to be considered by the structural engineer.
So, when we talk about loads, we are talking about much more than just the weight of objects.
A building can experience its own self-weight, the weight of walls and finishes, people and furniture, wind, earthquake effects and several other actions depending on its location and purpose. The job of the structural engineer is to understand these actions and make sure that the structure can safely deal with them.
What Does a Load Actually Do to a Structure?
This is where Strength of Materials becomes interesting.
Suppose I apply a downward force to a beam. The beam doesn't simply "take" the force and remain exactly as it was. It responds. It may bend slightly, it may deform, and internal forces develop within the beam. As the loading increases, the stresses and strains may also increase.
So there is a simple chain that I want you to keep in your mind throughout this entire series:
Load → Structural Response
A load is the external action. The deformation, internal forces, stresses and strains that develop because of that action are part of the structural response.
For example, if you stand on a wooden plank supported at both ends, your weight acts as an external load. The plank bends slightly. That bending is part of the response of the plank to the load.
This may sound very simple right now, but this idea is actually at the heart of a huge part of structural engineering.
Now Think About the Load Path
There is another concept that I want you to start noticing whenever you look at a building: Where does the load go?
Suppose a person is standing on a slab. The person's weight doesn't simply disappear there. The slab transfers the load to the supporting members. Those members transfer it further, and eventually the load reaches the foundation and then the ground.
In a simplified building, we can imagine the load travelling something like this:
Slab → Beam → Column → Foundation → Soil
This is what we commonly refer to as the load path.
Once you start thinking about structures in terms of load paths, you begin to look at buildings differently. Instead of just seeing a slab, beam and column as separate pieces of concrete, you start asking yourself how they work together to transfer forces safely to the ground.
That way of thinking is extremely important for a structural engineer.
A Small Experiment for You
Here's something you can actually try yourself.
Take a pen, ruler or any thin object and support it at two ends using two books. Now gently press its centre with your finger. Observe what happens. The member bends.
Now press a little harder. The deformation becomes larger.
You have just performed a very simple structural experiment.
Your finger is applying an external force. The member is responding to that force by deforming.
Of course, real structural engineering is much more complicated than this small experiment. We eventually need to calculate exactly how much a member bends, what stresses develop inside it, whether the material remains elastic, and whether the structure is safe. But before we learn all those equations, we need to understand what is physically happening.
And that is exactly how I want you to approach this entire Strength of Materials: Zero to Hero series.
First visualize it. Then understand it. Then calculate it.
What Are Some Common Forms of Loading?
Once the basic idea of a load is clear, we can start looking at how loads are represented in engineering.
A load can act at a particular location. We often idealize this as a point load. For example, imagine a person standing at a particular location on a beam. In a simplified structural model, the person's weight may be represented as a force acting at that point.
A load can also be spread over a length. This is called a distributed load. The weight transferred from a floor slab to a beam is often represented in this way. Instead of drawing one large arrow at one location, we may represent the loading using several arrows distributed along the beam.
Similarly, a structure can experience a moment, which tends to rotate a member. You will encounter moments repeatedly as we move forward into structural analysis, so don't worry if the concept isn't completely clear yet. We will build it from the basics when the time comes.
The important thing at this stage is not to memorize every type of load. Instead, I want you to become comfortable with the idea that different external actions can act on a structure in different ways, and the structure has to respond to them.
Let's Look at a Building
Imagine a typical reinforced concrete building.
The slab has its own weight. The walls add more weight. Furniture and people add additional loading. All these actions have to be transferred through the structural system.
The slab transfers its load to beams or directly to columns depending on the structural system. Beams transfer their forces to columns. Columns transfer the forces to the foundations, and the foundations finally transfer them to the soil.
So when you look at a building, try to imagine an invisible path running through it.
Where does the load start?
Where does it go next?
Which structural member receives it?
How does that member transfer it further?
These questions may seem basic, but they are the foundation of structural thinking.
One Important Distinction
There is a small distinction that is worth understanding early.
A load is the external action acting on the structure, while the structural response is what happens because of that action.
For example, suppose a person stands on a beam. The person's weight acts on the beam. That is the loading. The beam may then develop support reactions, bending, shear, stresses and deformation. Those are responses produced by the loading.
So, in a very simplified way:
Load is the cause. Structural response is the consequence.
As we progress through Strength of Materials, we will keep moving from one side of this relationship to the other. We will start with external loads, understand how structures respond to them, and eventually learn how to calculate that response.
Your Turn
Before you move on to the next lesson, look around you and choose any five objects or structures.
Maybe it's your chair. Maybe your table. Maybe a shelf. Maybe your bed. Maybe the floor beneath you.
For each one, ask yourself one simple question:
"What load is acting on this?"
Don't calculate anything yet.
Just observe.
If you can start looking at ordinary objects and automatically think about the loads acting on them, you're already beginning to develop an engineer's way of thinking.
So, What Have We Learned?
A load is an external action acting on a structure. It can come from many different sources, including the weight of the structure itself, people, furniture, vehicles, wind, earthquakes, pressure and other actions.
But the most important thing is not the definition. It is the physical idea behind it.
A structure is subjected to a load, and the structure responds.
That response can involve deformation, bending, internal forces, stresses and strains. The load also needs to travel through the structural system and ultimately reach the ground through a safe load path.
And now we are ready for the next question.
If a load acts on a structure... what can it actually do?
Can it bend a beam?
Can it stretch a member?
Can it compress a column?
Can it twist a shaft?
Can it crack or eventually cause failure?
That's what we'll explore in Lesson #2: What Can a Load Do to a Structure?
