Compressive Strength Test (Crushing Strength Test) [IS:1121 (Part 1)] Requirements:

Compressive Strength Test (Crushing Strength Test) of Stones

[IS:1121 (Part 1)]



Compressive Strength Test Of Stones | Crushing Test on Stones | Stone As A Building Material | Construction Materials | Stones | By Akhand Dutta




Explanatory Video:





Requirements:


  • Take samples of stones weighing at least 25 kg each.


  • Specimen species should be in the form of cubes or cylinders.


  • The lateral dimension or diameter should be of 50 mm at least.


  • The ratio of lateral dimension or ratio of height to diameter should be 1:1.


  • A minimum of three specimens should be used for testing.


Procedure:


  • Specimen is immersed in water at 20 to 30 °C for 72 hours. (Test in saturated condition)


  • Specimen is dried in an oven at 105 ± 5 °C for 24 hours. (Test in dry condition)


  • Then it is cooled in a desiccator to 20 to 30 °C.


  • Later, it is tested in Universal Testing Machine.


  • The load is gradually applied at a rate of 14 N /sq. mm /min (14 newtons per millimetre square per minute) until the specimen breaks down.

Compressive Strength Test Of Stones | Crushing Test on Stones | Stone As A Building Material | Construction Materials | Stones | By Akhand Dutta
Universal Testing Machine



The Compressive Strength is then calculated by the formula:


Compressive Strength Test Of Stones | Crushing Test on Stones | Stone As A Building Material | Construction Materials | Stones | By Akhand Dutta




*When the ratio of lateral dimension or ratio of height to diameter differs from unity by 25% or more then Compressive strength in Calculated by this formula:


Compressive Strength Test Of Stones | Crushing Test on Stones | Stone As A Building Material | Construction Materials | Stones | By Akhand Dutta


here,

Cp= compressive strength of standard specimen piece

b= diameter or lateral dimension

h= height



Revision Mind Map For Compressive Strength Test on Stone


Compressive Strength Test Of Stones | Crushing Test on Stones | Stone As A Building Material | Construction Materials | Stones | By Akhand Dutta
Revision Mind Map For Compressive Strength Test on Stone














*Self Typed

*Source- Internet, Books and Self-Analysis
